LOTUS EUROPA TC/TCS PARTS MANUALSection ME -- Electrical -- TaillightsLotus Europa Central -- Tech Specifications -- TC/TCS Parts Home -- Manuals Home -- Feedback |
|---|
| Click here to open a new window containing a searchable PDF copy. (170K) |
 |  |  |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 1 | X050M6059W | 1 | 1 | + | + | Assembly - Rear Lamp (L/H) | - More Info - | ||||||
| 1 | X050M6060W | 1 | 1 | + | + | Assembly - Rear Lamp (R/H) | - More Info - | ||||||
| 1 | A054M6081W | 1 | 1 | Assembly - Rear Lamp (L/H) | - More Info - | ||||||||
| 1 | A054M6080W | 1 | 1 | Assembly - Rear Lamp (R/H) | - More Info - | ||||||||
| 2 | X050M6061Z | 1 | 1 | + | + | Lens (L/H) | |||||||
| 2 | X050M6062Z | 1 | 1 | + | + | Lens (R/H) | |||||||
| 2 | A054M6095Z | 1 | 1 | Lens (L/H) | |||||||||
| 2 | A054M6096Z | 1 | 1 | Lens (R/H) | |||||||||
| 3 | A036M6331Z | 2 | 2 | 2 | 2 | Bulb (380) - Stop/tail | - More Info - | ||||||
| 4 | A036M6329Z | 2 | 2 | 2 | 2 | Bulb (382) - Flasher | - More Info - | ||||||
| 5 | A036M6332Z | 2 | 2 | 2 | 2 | Bulb (272) - Reverse | - More Info - | ||||||
| 5 | XUFB0308 | 6 | 6 | 6 | 6 | Bolt - Rear Lamp Mounting | |||||||
| 5 | 105 | 6 | 6 | 6 | 6 | Washer | |||||||
| 5 | X036M0127W | 2 | + | Unit - Fuse (West Germany Only) | |||||||||
| 5 | A050M6167Z | 2 | + | Fuse - 5 amp. (West Germany Only) |
